• ROTARY SWITCH

  • Rotary switch

    1101 Rotary switch

    SPECIFICATION:

    RATING : 3A 125VAC, 1.5A 250VAC
     INSULATION RESISTANCE :     DC 500V 100MΩ OR MORE
     CONTACT RESISTANCE : DC 2-4V 1A 20mΩ OR LESS
     WITHSTAND VOLTAGE : AC 1500V FOR 1 Min

    Inquiry Info. More information

  • Rotary switch

    1107 Rotary switch

    SPECIFICATION:

    RATING :

    5A 125VAC, 2.5A 250VAC (UL,CUL)

    0.5A 125VDC

    CIRCUIT : FROM 1P1T TO 1P5T

    INSULATION RESISTANCE : DC 500V 100MΩ OR MORE

    CONTACT RESISTANCE : DC 2-4V 1A 20mΩ OR LESS

    WITHSTAND VOLTAGE : AC 1500V FOR 1 Min

    ELECTRICAL LIFE : 6,000 CYCLES

    Inquiry Info. More Information

  • Rotary switch

    2108E Rotary switch

    SPECIFICATION:

    RATING :
    1/3HP 125/250VAC, 25A 125/250VAC (UL,CUL)
    20.2A 125/250VAC, 30.2A 125/250VAC (UL,CUL)
     INSULATION RESISTANCE :     DC 500V 100MΩ OR MORE
     CONTACT RESISTANCE : DC 2-4V 1A 30mΩ OR LESS
     WITHSTAND VOLTAGE : AC 1500V FOR 1 Min
     AMBIENT TEMPERATURE: 0~55℃
     ELECTRICAL LIFE :     6,000 CYCLES

    Inquiry Info. More Information

  • Rotary switch

    2121 Series Rotary switch

    SPECIFICATION:

    RATING : 16A 125/250VAC (UL, CUL)
    INSULATION RESISTANCE : DC 500V 100MΩ OR MORE
     CONTACT RESISTANCE : DC 2-4V 1A 20mΩ OR LESS
     WITHSTAND VOLTAGE : AC 1500V FOR 1 Min
     AMBIENT TEMPERATURE : 0~105℃
     ELECTRICAL LIFE : 6,000 CYCLES
    　

    Inquiry Info. More Information

  • Rotary switch

    2134E Rotary switch

    SPECIFICATION:

    RATING :
    1/3HP 125/250VAC, 25A 125/250VAC (UL,CUL)
    20.2A 125/250VAC, 30.2A 125/250VAC (UL,CUL)
     INSULATION RESISTANCE : DC 500V 100MΩ OR MORE
     CONTACT RESISTANCE : DC 2-4V 1A 20mΩ OR LESS
     WITHSTAND VOLTAGE : AC 1500V FOR 1 Min
    AMBIENT TEMPERATURE: 0~55℃
     ELECTRICAL LIFE :     6,000 CYCLES


    Inquiry Info. More Information

  • Rotary switch

    2141B Rotary switch

    SPECIFICATION:

    RATING :
    1/3HP 125/250VAC, 25A 125/250VAC (UL,CUL)
    20.2A 125/250VAC, 30.2A 125/250VAC (UL,CUL)
    8A 250V~ 30A 250V~u (ENEC)
    INSULATION RESISTANCE : DC 500V 100MΩ OR MORE
     CONTACT RESISTANCE : DC 2-4V 1A 20mΩ OR LESS
     WITHSTAND VOLTAGE : AC 1500V FOR 1 Min
    AMBIENT TEMPERATURE: 0~55℃
     ELECTRICAL LIFE : 10,000 CYCLES

    Inquiry Info. More Information

  • Rotary switch

    2144B Rotary switch

    SPECIFICATION:

    RATING : 10.1A 125VAC (UL,CUL)

    INSULATION RESISTANCE : DC 500V 100MΩ OR MORE

    CONTACT RESISTANCE : DC 2-4V 1A 30mΩ OR LESS

    WITHSTAND VOLTAGE : AC 1500V FOR 1 Min





    Inquiry Info. More Information

  • Rotary switch

    2145 Rotary switch

    SPECIFICATION:

    RATING : 6A 250VAC, 10A 125VAC, 16A 125/250VAC
     INSULATION RESISTANCE : DC 500V 100MΩ OR MORE
     CONTACT RESISTANCE : DC 2-4V 1A 20mΩ OR LESS
     WITHSTAND VOLTAGE : AC 1500V FOR 1 Min

    Inquiry Info. More Information

  • Rotary switch

    2146 Rotary switch

    SPECIFICATION:

    RATING :

    25A 125VAC 1 1/4HP

    25A 250VAC 2HP

    21A 125/250VAC

    6A 125/250VAC 1/4HP

    INSULATION RESISTANCE : DC 500V 100MΩ OR MORE

    CONTACT RESISTANCE : DC 2-4V 1A 30mΩ OR LESS

    WITHSTAND VOLTAGE : AC 1000V FOR 1 Min

    Inquiry Info. More Information

  • Rotary switch

    8105 Series Rotary switch

    SPECIFICATION:

    RATING : 5A 250VAC, 16A 250VAC
     INSULATION RESISTANCE :     DC 500V 100MΩ OR MORE
     CONTACT RESISTANCE : DC 2-4V 1A 20mΩ OR LESS
     WITHSTAND VOLTAGE : AC 1500V FOR 1 Min

    Inquiry Info. More information

Total of 10 results
